Reduce testing time, increase clinical insights with confidence.
AP-600 Automated Perimeter is a compact fully featured visual field analyzer that is simple to set up and use. Brilliant design combined with intuitive proprietary software offers expanded testing options to optimize your patient management with new TIA™ Standard, Fast and Superfast tests.
Fully Automated Test Sequence
Simplifies the perimetry process with guided instructions and minimal user input required.
Real-Time Eye Tracking
Ensures accurate results with continuous fixation monitoring and automatic pauses during loss of focus.
Portable & Lightweight
Designed for mobility in any clinical setting, allowing for in-room or bedside testing without compromising precision.
Comprehensive Report Generation
Automatically generates easy-to-read PDF visual field reports, ready for export or EMR upload.
Patient Comfort Focused
Short testing time, ergonomic design, and minimal light exposure reduce fatigue and improve patient compliance.
FDA Cleared and built with high safety standards, suitable for daily use in both hospitals and private clinics.
The PalmScan AP600 is an advanced, compact visual field analyzer designed for rapid, precise, and user-friendly perimetry testing. With a modern, portable build and intuitive software interface, it offers a seamless experience for both clinicians and patients.
Key Technical Specifications:
Testing Modes: Full threshold, Fast threshold, Suprathreshold
Test Strategies: Central 30°, 24°, 10°, Nasal Step, Custom patterns
Stimulus Size: Goldmann Size III
Stimulus Color: White
Background Illumination: 31.5 asb (Apostilbs)
Fixation Monitoring: Built-in video gaze tracker with real-time tracking
Fixation Target: LED with automatic fixation loss detection
Patient Response Mechanism: Ergonomic hand-held push button
Display Resolution: High-resolution LED display
Head Positioning: Comfortable chin rest with adjustable support
Testing Time: As short as 3 minutes for Fast Threshold
Memory & Storage: Internal memory with USB export and EMR integration
Printer Compatibility: Supports both thermal and external printers
Connectivity: USB, Wi‑Fi, and optional Bluetooth
Power Supply: 100–240V AC, 50/60Hz, with backup battery operation
